Troubleshooting by Indication on the Remote Controller Si34-803
292 Troubleshooting
Troubleshooting
Are there
any foreign matters around
the fan?
YES
NO
NO
NO
Any of
the fan motor
connectors X1A and
X3A or the relay harness
connectors Z5C, Z9C,
and X1A is
disconnected.
YES
NO
Connectors
of harness between
the compressor inverter
PC board and the fan
inverter PC board (A4P
and A8P)
are
disconnected.
Different
power supply
cable connector and
signal cable connector
have been connected to the
relay harness. (Power supply
and signal cable connectors
of different colors are
connected for one
and the same
motor.)
YES
YES
NO
NO
The fuse
(white tubular fuse)
on the fan inverter PC board has
a broken wire (has no
continuity).
YES
NO
Resitance
between the fan motor
power supply cable terminal
and the motor frame
(metal part) is not
more than
1MΩ.
With
the connector
disconnected from the
fan motor, the fan
cannot be rotated
by hand.
YES
YES
Caution
Be sure to turn off power switch before connect or disconnect connector,
or parts damage may be occurred.
Turn OFF the power supply,
and then wait for a period of 10
minutes.
Remove the foreign matters.
Insert the connector
disconnected.
Use connectors of the same
color in combination for the
power supply and signal
cables for the relay harness
(e.g. natural color to natural
color, or red to red).
Insert the connectors in the
harness.
Replace the fan inverter PC
board.
Replace the outdoor unit fan
motor.
Replace the outdoor unit fan
motor.
A
