Si34-803 Specifications
Specifications 45
Notes:
★1 Indoor temp. : 27°CDB, 19.5°CWB / outdoor temp. : 35°CDB / Equivalent piping length : 7.5m, level
difference : 0m.
★2 Indoor temp. : 27°CDB, 19.0°CWB / outdoor temp. : 35°CDB / Equivalent piping length : 7.5m, level
difference : 0m.
★3 Indoor temp. : 20°CDB / outdoor temp. : 7°CDB, 6°CWB / Equivalent piping length : 7.5m, level difference :
0m.
4 The units with anti-corrosion treatment will be available as standard. Please specify the suffix “E” as
RXYQ5PAYLE.
Model Name (Combination Unit)
YL(E)
RXYQ54PAYL(E)
Model Name (Independent Unit) RXYQ18PAYL(E)+RXYQ18PAYL(E)+RXYQ18PAYL(E)
Model Name (Combination Unit)
TL(E)
RXYQ54PTL(E)
Model Name (Independent Unit) RXYQ18PTL(E)+RXYQ18PTL(E)+RXYQ18PTL(E)
★1 Cooling Capacity (19.5°CWB)
kcal / h 127,000
Btu / h 505,000
kW 148
★
2 Cooling Capacity (19.0°CWB)
kW
147
★
3 Heating Capacity
kcal / h 146,000
Btu / h 580,000
kW 170
Casing Color
Without(E)
Ivory White (5Y7.5/1)
With(E) Light Camel (2.5Y6.5/1.5)
Dimensions: (H×W×D) mm (1680×1240×765)+(1680×1240×765)+(1680×1240×765)
Heat Exchanger Cross Fin Coil
Comp.
Type Hermetically Sealed Scroll Type
Piston
Displacement
m³/h
YL(E) (12.84+12.52+12.52)+(12.84+12.52+12.52)+(12.84+12.52+12.52)
TL(E) (12.84+12.52+12.52)+(12.84+12.52+12.52)+(12.84+12.52+12.52)
Number of
Revolutions
r.p.m
YL(E) (6060, 3450, 3450)+(6060, 3450, 3450)+(6060, 3450, 3450)
TL(E) (6060, 3450, 3450)+(6060, 3450, 3450)+(6060, 3450, 3450)
Motor Output×Number
of Units
kW ((4.3+4.5+4.5)×1)+((4.3+4.5+4.5)×1)+((4.3+4.5+4.5)×1)
Starting Method Soft Start
Fan
Type Propeller Fan
Motor Output kW (0.75×2)+(0.75×2)+(0.75×2)
Air Flow Rate m³/min 239+239+239
Drive Direct Drive
Connecting
Pipes
Liquid Pipe mm φ19.1 (Brazing Connection)
Gas Pipe mm φ41.3 (Brazing Connection)
Product Mass (Machine Weight) kg 341+341+341
Safety Devices High Pressure Switch, Fan Driver Overload Protector, Over Current Relay, Inverter Overload Protector
Defrost Method Deicer
Capacity Control % 3~100
Refrigerant
Refrigerant Name R-410A
Charge kg 11.7+11.7+11.7
Control Electronic Expansion Valve
Refrigerator Oil Refer to the nameplate of compressor
Standard Accessories Installation Manual, Operation Manual, Connection Pipes, Clamps
Drawing No.
Conversion Formulae
kcal/h=kW×860
Btu/h=kW×3412
cfm=m³/min×35.3
