Si34-803 Option List
Appendix 421
4.2 Option Lists (Outdoor Unit)
RXYQ5 ~ 18PAY1, PAYL, PTL
C : 3D053052C
RXYQ20 ~ 36PAY1, PAYL, PTL
C : 3D053052C
RXYQ38 ~ 54PAY1, PAYL, PTL
C : 3D053052C
Note): Order products
Optional accessories
RXYQ5PAY1, PAYL, PTL
RXYQ5PAY1E, PAYLE, PTLE
RXYQ8PAY1, PAYL, PTL
RXYQ10PAY1, PAYL, PTL
RXYQ8PAY1E, PAYLE, PTLE
RXYQ10PAY1E, PAYLE, PTLE
RXYQ12PAY1, PAYL, PTL
RXYQ14PAY1, PAYL, PTL
RXYQ16PAY1, PAYL, PTL
RXYQ18PAY1, PAYL, PTL
RXYQ12PAY1E, PAYLE, PTLE
RXYQ14PAY1E, PAYLE, PTLE
RXYQ16PAY1E, PAYLE, PTLE
RXYQ18PAY1E, PAYLE, PTLE
Cool/Heat Selector
KRC19-26A
Cool/Heat
Selector
Fixing box
KJB111A
Distributive
Piping
Refnet header
KHRP26M22H
(Max. 4 branch)
KHRP26M22H,
(Max. 4 branch)
KHRP26M33H
(Max. 8 branch)
KHRP26M22H, KHRP26M33H,
(Max. 4 branch) (Max. 8 branch)
KHRP26M72H
(Max. 8 branch)
Refnet joint KHRP26A22T
KHRP26A22T,
KHRP26A33T
KHRP26A22T, KHRP26A33T,
KHRP26A72T
Outdoor unit multi connection piping kit
—
Central drain pan kit
KWC26C160
KWC26C160E
KWC26C280
KWC26C280E
KWC26C450
KWC26C450E
Digital Pressure Gauge Kit
BHGP26A1(E)
Optional accessories
RXYQ20PAY1, PAYL, PTL
RXYQ22PAY1, PAYL, PTL
RXYQ20PAY1E, PAYLE, PTLE
RXYQ22PAY1E, PAYLE, PTLE
RXYQ24PAY1, PAYL, PTL
RXYQ26PAY1, PAYL, PTL
RXYQ28PAY1, PAYL, PTL
RXYQ24PAY1E, PAYLE, PTLE
RXYQ26PAY1E, PAYLE, PTLE
RXYQ28PAY1E, PAYLE, PTLE
RXYQ30PAY1, PAYL, PTL
RXYQ32PAY1, PAYL, PTL
RXYQ34PAY1, PAYL, PTL
RXYQ36PAY1, PAYL, PTL
RXYQ30PAY1E, PAYLE, PTLE
RXYQ32PAY1E, PAYLE, PTLE
RXYQ34PAY1E, PAYLE, PTLE
RXYQ36PAY1E, PAYLE, PTLE
Cool/Heat Selector
KRC19-26A
Cool/Heat
Selector
Fixing box
KJB111A
Distributive
Piping
Refnet header
KHRP26M22H
(Max. 4 branch),
KHRP26M33H
(Max. 8 branch),
KHRP26M72H
(Max. 8 branch)
KHRP26M22H, KHRP26M33H, KHRP26M72H, KHRP26M73H
(Max. 4 branch) (Max. 8 branch) (Max. 8 branch) (Max. 8 branch)
Refnet joint
KHRP26A22T,
KHRP26A33T,
KHRP26A72T
KHRP26A22T, KHRP26A33T, KHRP26A72T, KHRP26A73T
Outdoor unit multi connection piping kit
BHFP22P100
Pipe size reducer
— KHRP26M73TP, KHRP26M73HP
Central drain pan kit
KWC26C280
KWC26C450
KWC26C280E
KWC26C450E
KWC26C280
KWC26C450
KWC26C280E
KWC26C450E
KWC26C450×2
KWC26C450E×2
Digital Pressure Gauge Kit
BHGP26A1(E)
Optional accessories
RXYQ38PAY1, PAYL, PTL
RXYQ40PAY1, PAYL, PTL
RXYQ42PAY1, PAYL, PTL
RXYQ44PAY1, PAYL, PTL
RXYQ46PAY1, PAYL, PTL
RXYQ38PAY1E, PAYLE, PTLE
RXYQ40PAY1E, PAYLE, PTLE
RXYQ42PAY1E, PAYLE, PTLE
RXYQ44PAY1E, PAYLE, PTLE
RXYQ46PAY1E, PAYLE, PTLE
RXYQ48PAY1, PAYL, PTL
RXYQ50PAY1, PAYL, PTL
RXYQ52PAY1, PAYL, PTL
RXYQ54PAY1, PAYL, PTL
RXYQ48PAY1E, PAYLE, PTLE
RXYQ50PAY1E, PAYLE, PTLE
RXYQ52PAY1E, PAYLE, PTLE
RXYQ54PAY1E, PAYLE, PTLE
Cool/Heat Selector
KRC19-26A
Cool/Heat
Selector
Fixing box
KJB111A
Distributive
Piping
Refnet header
KHRP26M22H, KHRP26M33H, KHRP26M72H, KHRP26M73H
(Max. 4 branch) (Max. 8 branch) (Max. 8 branch) (Max. 8 branch)
Refnet joint KHRP26A22T, KHRP26A33T, KHRP26A72T, KHRP26A73T
Outdoor unit multi connection piping kit
BHFP22P151
Pipe size reducer
KHRP26M73TP, KHRP26M73HP
Central drain pan kit
KWC26C280
KWC26C450×2
KWC26C280E
KWC26C450E
×2
KWC26C450×3
KWC26C450E
×3
Digital Pressure Gauge Kit
BHGP26A1(E)
