Specifications Si34-803
44 Specifications
Notes:
★1 Indoor temp. : 27°CDB, 19.5°CWB / outdoor temp. : 35°CDB / Equivalent piping length : 7.5m, level
difference : 0m.
★2 Indoor temp. : 27°CDB, 19.0°CWB / outdoor temp. : 35°CDB / Equivalent piping length : 7.5m, level
difference : 0m.
★3 Indoor temp. : 20°CDB / outdoor temp. : 7°CDB, 6°CWB / Equivalent piping length : 7.5m, level difference :
0m.
4 The units with anti-corrosion treatment will be available as standard. Please specify the suffix “E” as
RXYQ5PAYLE.
Model Name (Combination Unit)
YL(E)
RXYQ50PAYL(E) RXYQ52PAYL(E)
Model Name (Independent Unit) RXYQ14PAYL(E)+RXYQ18PAYL(E)+RXYQ18PAYL(E) RXYQ16PAYL(E)+RXYQ18PAYL(E)+RXYQ18PAYL(E)
Model Name (Combination Unit)
TL(E)
RXYQ50PTL(E) RXYQ52PTL(E)
Model Name (Independent Unit) RXYQ14PTL(E)+RXYQ18PTL(E)+RXYQ18PTL(E) RXYQ16PTL(E)+RXYQ18PTL(E)+RXYQ18PTL(E)
★1 Cooling Capacity (19.5°CWB)
kcal / h 120,000 124,000
Btu / h 474,000 491,000
kW 139 144
★
2 Cooling Capacity (19.0°CWB)
kW
138 143
★
3 Heating Capacity
kcal / h 136,000 140,000
Btu / h 539,000 556,000
kW 158 163
Casing Color
Without(E)
Ivory White (5Y7.5/1) Ivory White (5Y7.5/1)
With(E) Light Camel (2.5Y6.5/1.5) Light Camel (2.5Y6.5/1.5)
Dimensions: (H×W×D) mm (1680×1240×765)+(1680×1240×765)+(1680×1240×765) (1680×1240×765)+(1680×1240×765)+(1680×1240×765)
Heat Exchanger Cross Fin Coil Cross Fin Coil
Comp.
Type Hermetically Sealed Scroll Type Hermetically Sealed Scroll Type
Piston
Displacement
m³/h
YL(E)
(12.84+12.52+12.52)+(12.84+12.52+12.52)+(12.84+12.52+12.52) (12.84+12.52+12.52)+(12.84+12.52+12.52)+(12.84+12.52+12.52)
TL(E)
(12.84+12.52+12.52)+(12.84+12.52+12.52)+(12.84+12.52+12.52) (12.84+12.52+12.52)+(12.84+12.52+12.52)+(12.84+12.52+12.52)
Number of
Revolutions
r.p.m
YL(E)
(6060, 3450, 3450)+(6060, 3450, 3450)+(6060, 3450, 3450) (6060, 3450, 3450)+(6060, 3450, 3450)+(6060, 3450, 3450)
TL(E)
(6060, 3450, 3450)+(6060, 3450, 3450)+(6060, 3450, 3450) (6060, 3450, 3450)+(6060, 3450, 3450)+(6060, 3450, 3450)
Motor Output×Number
of Units
kW ((1.6+4.5+4.5)×1)+((4.3+4.5+4.5)×1)+((4.3+4.5+4.5)×1) ((2.7+4.5+4.5)×1)+((4.3+4.5+4.5)×1)+((4.3+4.5+4.5)×1)
Starting Method Soft Start Soft Start
Fan
Type Propeller Fan Propeller Fan
Motor Output kW (0.35×2)+(0.75×2)+(0.75×2) (0.35×2)+(0.75×2)+(0.75×2)
Air Flow Rate m³/min 233+239+239 233+239+239
Drive Direct Drive Direct Drive
Connecting
Pipes
Liquid Pipe mm φ19.1 (Brazing Connection) φ19.1 (Brazing Connection)
Gas Pipe mm φ41.3 (Brazing Connection) φ41.3 (Brazing Connection)
Product Mass (Machine Weight) kg 329+341+341 329+341+341
Safety Devices
High Pressure Switch, Fan Driver Overload Protector, Over
Current Relay, Inverter Overload Protector
High Pressure Switch, Fan Driver Overload Protector, Over
Current Relay, Inverter Overload Protector
Defrost Method Deicer Deicer
Capacity Control % 3~100 3~100
Refrigerant
Refrigerant Name R-410A R-410A
Charge kg 11.3+11.7+11.7 11.5+11.7+11.7
Control Electronic Expansion Valve Electronic Expansion Valve
Refrigerator Oil Refer to the nameplate of compressor Refer to the nameplate of compressor
Standard Accessories
Installation Manual, Operation Manual, Connection Pipes,
Clamps
Installation Manual, Operation Manual, Connection Pipes,
Clamps
Drawing No.
Conversion Formulae
kcal/h=kW×860
Btu/h=kW×3412
cfm=m³/min×35.3
