SPECIFICATIONS AND OPTIONS
13
New2001New2001
Specifications ■
General D
•Frequencycoverage:
Tx 156.025–157.425 MHz
Rx 156.050–163.275 MHz
CH70 156.525 MHz
•Mode:
FM (16K0G3E),
DSC (16K0G2B)
•Channelspacing: 25kHz
•Operatingtemp.range:
–20°C to +60°C (–4ºF to +140ºF)
•Currentdrain(at13.8V): TXhigh 5.5Amaximum
Max. audio 5.0 A maximum
(With EXT SP)
Max. audio 1.5 A maximum
(With INT SP)
•Powersupplyrequirement: 13.8V DC ±15%
(negative ground)
•Frequencytolerance: ±10ppm(–20°Cto+60°C;
–4ºF to +140ºF
)
•Antennaimpedance: 50˘ nominal
•Dimensions: 178.9(W)× 113.9 (H) ×
(Projections not included) 113.8 (D) mm
7 (W) × 4.5 (H) × 4.5 (D) inches
•Weight(approximately): 1.4kg;3.1lb
Transmitter D
•Outputpower: 25W/1W
•Modulationsystem: Variablereactancefrequency
modulation
•Max.frequencydeviation: ±5.0kHz
•Spuriousemissions: Lessthan–70dBc(high)
Less than –56 dBc (low)
Receiver D
•Receivesystem: Doubleconversion
superheterodyne
•Sensitivity(12dBSINAD): –13dBµ(typical)
–5dBµemf(typical)
(CH70/DSC) (1% BER)
•Squelchsensitivity: Lessthan–7dBµ
•Intermodulationrejectionratio: Morethan75dB
Morethan68dBµemf
(CH70/DSC) (1% BER)
•
Spurious response rejection ratio
: More than 75 dB
Morethan73dBµemf
(CH70/DSC) (1% BER)
•Adjacentchannelselectivity: Morethan75dB
Morethan75dBµemf
(CH70/DSC) (1% BER)
•Audiooutputpower: Morethan15Wat10%distor-
tion with an external speaker
(4 ˘ load)
