D Dimensions
Options ■
•MB-75/MB-132 f l u s h m o u n t K i t
To mount the transceiver to a panel.
•HM-205B/HM-205RB
s p e a K e r m i c r o p h o n e
Equipped with [Y]/[Z] (channel up/down,) [H/L], [16/C] and
[PTT] keys, a speaker and microphone.
•HM-195B/HM-195SW
c o m m a n d m i c IV™
External microphone-type controller. Provides optional in-
tercom operation. 6 meters (20 feet) microphone cable and
mounting base included. Black and white colors are avail-
able.
HM-195B: Black
HM-195SW: Super White
•OPC-1541
m i c r o p h o n e e x t e n s i o n c a b l e
6 meters (20 feet) microphone extension cable for optional
HM-195
c o m m a n d m i c IV™. Up to two OPC-1541 can be
connected. Usable length is 18 meters (60 feet) maximum.
•MA-500TR
c l a s s b a i s t r a n s p o n d e r
To transmit individual DSC calls to a selected AIS targets.
•UT-112
v o i c e s c r a m b l e r u n i t
Ensures private communications. 32 codes are available.
Not available in some countries.
Ask your service center or technical dealer for installation
details.
Approved Icom optional equipment is designed for optimal perfor-
mance when used with an Icom transceiver.
Icom is not responsible for the destruction or damage to an Icom
transceiver in the event the Icom transceiver is used with equipment
that is not manufactured or approved by Icom.
113.9 (4.5) 113.8 (4.5)
157 (6.2)
25 (1) 104 (4.1)
93.4 (3.7)
Unit: mm (inch)
