When no GPS receiver is connected, and both position
and time have been manually programmed, the screen
as shown below appears. Edit your latitude and longitude
position and UTC time as follows:
Push [CHG], then edit your latitude and longitude posi- ➥
tion and UTC time.
•Selectadesirednumberusing[Y]/[Z]/[Ω]/[≈].
•Push[ENT]ordialtosetit.
•Tomovethecursor,rotatedialorselecteitherarrow,“←” or
“→,” then push [ENT] or Dial.
•SelectN(Northlatitude)orS(Southlatitude)whenthecur-
sor is on the ‘N’ or ‘S’ position.
•SelectW (West longitude) orE (East longitude) whenthe
cursor is on the ‘W’ or ‘E’ position.
