25
7
DSC OPERATION
New2001
D Regular call (continued)
t After transmitting the call, the transceiver waits for an ac-
knowledgment call.
•The Distress call is automatically transmitted every 3.5 to 4.5
minutes, until an acknowledgement is received (‘Call repeat’
mode), or DSC cancel call is made. (p. 27)
•Push[RESEND]tomanuallytransmittheDistressrepeatcall.
•Push [Ω]/[≈] then push [INFO] to display the transmitted Dis-
tress call information.
•Push[Ω]/[≈] then push [PAUSE] to pause the ‘Call repeat’ mode,
push [RESUME COUNTDOWN] to resume it.
y After receiving an acknowledgment call, push [ALARM
OFF] then reply using the microphone.
➥ A distress alert contains:
•Natureofdistress: Selectedinstepw.
•Positioninformation:The latest GPS or manual input position
is held for 23.5 hours, or until the power is
turned OFF.
