84
9
AIS RECEIVER (Depending on versions)
New2001
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
D Content lists of Class B vessels’ DETAIL
screens
•AISClass
•MMSICode
•ShipName
•CountryName
•CallSign
•VendorID
•CPA(ClosestPointof
Approach)
•TCPA(TimetoCPA)
•Position(Latitude,
Longitude)
•SpeedOverGround
•CourseOverGround
•Heading
•PositionAccuracy
(H: High, L: Low)
•Range
•Bearing
•BowtoAntennalength
•SterntoAntennalength
•PortsidetoAntenna
length
• Starboard side to Antenna
length
•Length
•Beam
•TypeofShip
•AISClass
•MMSICode
•Position(Latitude,
Longitude)
•PositionAccuracy
(H: High, L: Low)
•Range
•Bearing
•AISClass
•MMSICode
•Position(Latitude,
Longitude)
•SpeedOverGround
•CourseOverGround
•PositionAccuracy
(H: High, L: Low)
•Range
•Bearing
•Altitude
D Content lists of SAR targets’ DETAIL
screens
D Content lists of Base Station targets’ DE-
TAIL screens
•AISClass
(AtoN existence
(REAL, VIRTUAL))
•MMSICode
•TargetName
•CPA(ClosestPointof
Approach)
•TCPA(TimetoCPA)
•Position(Latitude,
Longitude)
•PositionAccuracy
(H: High, L: Low)
•Range
•Bearing
•BowtoAntennalength
•SterntoAntennalength
•PortsidetoAntenna
length
• Starboard side to Antenna
length
•Length
•Beam
•PositionIndicator
(ON POS : ON Position,
OFF POS : OFF Position)
•TypeofAtoN
D Content lists of AtoN targets’ DETAIL
screens
