Icom IC-M506 [94/124] Ais receiver depending on versions
![Icom IC-M506 [94/124] Ais receiver depending on versions](/views2/1074276/page94/bg5e.png)
New2001
85
9
AIS RECEIVER (Depending on versions)
New2001
D Content lists of AIS-SART targets’ DETAIL
screens
•TypeofAISTarget
•MMSICode
•CallSign
•IMONumber
•ClosestPointof
Approach
•TCPA(TimetoCPA)
•Position(Latitude,
Longitude)
•SpeedOverGround
•CourseOverGround
•Heading
•PositionAccuracy
(H: High, L: Low)
•Range
•Bearing
•RateOfTurn
•BowtoAntennalength
•SterntoAntennalength
•PortsidetoAntenna
length
• Starboard side to Antenna
length
•Length
•Beam
•Draught
•TypeofShip
•NavigationStatus
•Destination
•Date
•Time
D Content lists of MOB targets’ DETAIL
screens
•TypeofAISTarget
•MMSICode
•CallSign
•IMONumber
•ClosestPointofApproach
•TCPA(TimetoCPA)
•Position(Latitude,
Longitude)
•SpeedOverGround
•CourseOverGround
•Heading
•PositionAccuracy
(H: High, L: Low)
•Range
•Bearing
•RateOfTurn
•BowtoAntennalength
•SterntoAntennalength
•PortsidetoAntenna
length
• Starboard side to Antenna
length
•Length
•Beam
•Draught
•TypeofShip
•NavigationStatus
•Destination
•Date
•Time
