ACCESSORY ATTACHMENT
New2001 New2001
■ Hand strap
Slide the hand strap through the loop on the right top of the
receiver as illustrated below to facilitate carrying the receiver.
■ Battery installation
Install the Li-Ion battery pack (BP-244) or optional battery
case
(BP-262) as follows.
q
Remove the battery cover from the receiver.
Latch
w Install the Li-Ion battery pack (BP-244).
• Be sure to observe the correct direction.
• Charge the Li-Ion battery pack before use. (p. 12)
Facing up this side
Handstrap
