Icom IC-RX7 [93/108] Lcd contrast
![Icom IC-RX7 [93/108] Lcd contrast](/views2/1074718/page93/bg5d.png)
85
9
OTHER FUNCTIONS
New2001
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
■ LCD contrast
The contrast of the LCD can be selected from 15 levels.
This can be selected with “LCD CONTRAST” in DIAPLAY
menu.
MENU ➪ DISPLAY ➪ LCD CONTRAST (p. 72)
(Push [MENU ]), (Push [r]/[s], then push [ENT MW].)
■ Voice squelch control
This function is useful when you don’t want unmodulated
signals pausing or cancelling a search/scan. When the voice
squelch control function is activated, the receiver checks
received signals for voice components. If a received sig-
nal includes voice components, and the tone of the voice
components changes within 1 sec., search/scan pauses (or
stops). If the received signal includes no voice components
or the tone of the voice components does not change within
1 sec., scan resumes.
This can be selected with “VSC” in MODE/TS/TONE... menu.
MENU ➪ MODE/TS/TONE... ➪ VSC (p. 65)
(Push [MENU ]), (Push [r]/[s], then push [ENT MW].)
• “VSC” appears when the function is activated.
