Icom IC-RX7 [96/108] Control command
![Icom IC-RX7 [96/108] Control command](/views2/1074718/page96/bg60.png)
New2001
88
New2001
CONTROL COMMAND
10
■ General
The IC-RX7 can be connected to a PC via the PC’s RS-
232C port using an optional CT-17
CI-V LEVEL CONVERTER.
This allows you to control the receiver from the PC and/or
transfer data from the receiver to the PC.
Control is provided via Icom’s CI-V Communication Interface.
An appropriate application for CI-V command is not sup-
plied from Icom.
■ Data format
The CI-V system can be operated using the following data
formats. Data formats differ according to command numbers.
A data area is added for some commands.
Controller ➡ IC-RX7
IC-RX7 ➡ Controller
q Preamble code (fixed)
w Receiver’s default address
e Controller’s default address
r Command number (see table below)
t Sub command number (see table below)
y
BCD code data for frequency/mode/Squelch condition entry
u End of message code (fixed)
■ Command table
FE FE 78 E0 Cn Sc Data area FD
q w e r t y u
FE
FE E0 78 Cn Sc Data area FD
q e w r t y u
Description Cn Sc
Transfers frequency data (transceive) 00 —
Transfers mode data (transceive) 01 —
Reads display frequency 03 —
Reads display mode 04 —
Sets frequency data 05 —
Sets AM mode
06
02
Sets FM mode 05
Sets WFM mode 06
Reads squelch condition (open or closed)
15
01
Reads S-meter level
02
