ACCESSORY ATTACHMENT
1
■ Antenna
Screw down the antenna as shown below.
NEVER carry the receiver by hold-
ing the antenna.
✔ For your information
Some high quality third party antennas may increase
receiver performance. An optional AD-92SMA antenna
connector adapter is available to connect an antenna
with a BNC connector.
■ Belt clip
Slide the supplied belt clip on the receiver’s rear panel until it
clicks into place.
Belt clip
Pull this lever when
detached
Antenna
