Icom IC-7700 [103/216] D filter shape set mode continued
![Icom IC-7700 [103/216] D filter shape set mode continued](/views2/1074139/page103/bg67.png)
5-15
DD
Filter shape set mode (continued)
5
FUNCTIONS FOR RECEIVE
Select the filter shape for SSB mode in HF bands. The set filter shape is automatically used only
when the IF filter is set to 600 Hz or wider.
HF SSB (600Hz – )
SHARP
Select the filter shape for SSB data mode in HF
bands.
The set filter shape is automatically used only
when the IF filter is set to 600 Hz or wider.
SSB–D (600Hz – )
SHARP
Select the filter shape for CW mode in HF bands. The set filter shape is automatically used only
when the IF filter is set to 500 Hz or narrower.
CW ( – 500Hz)
SHARP
Select the filter shape for CW mode in HF bands. The set filter shape is automatically used only
when the IF filter is set to 600 Hz or wider.
CW (600Hz – )
SHARP
Select the filter shape for SSB mode in 50 MHz band. The set filter shape is automatically used only
when the IF filter is set to 600 Hz or wider.
50M SSB (600Hz – )
SOFT
Select the filter shape for SSB data mode in 50 MHz
band.
The set filter shape is automatically used only
when the IF filter is set to 600 Hz or wider.
SSB–D (600Hz – )
SHARP
Select the filter shape for CW mode in 50 MHz band. The set filter shape is automatically used only
when the IF filter is set to 500 Hz or narrower.
CW ( – 500Hz)
SHARP
Select the filter shape for CW mode in 50 MHz band. The set filter shape is automatically used only
when the IF filter is set to 600 Hz or wider.
CW (600Hz – )
SHARP
