Icom IC-7700 [82/216] D convenient functions for transmit
![Icom IC-7700 [82/216] D convenient functions for transmit](/views2/1074139/page82/bg52.png)
4-30
4
RECEIVE AND TRANSMIT
• VOX (voice operated transmit) (p. 6-2)
➥ Push to turn the VOX function ON and
OFF.
•“ ” appears when the VOX function is ON.
•Transmit quality monitor (p. 6-4)
➥ Push to turn the monitor function ON
and OFF.
• Rotate [MONI GAIN] to adjust the monitor gain.
• Monitor indicator (above switch) lights
when the monitor function is ON.
• Audio tone control (p. 12-5)
➥ Push [SET] then [LEVEL] to enter level
set mode. Select an item with [Y] /[Z]
then rotate the main dial to adjust the audio tone.
F-2F-1
F-1F-7
MONITOR
MONITOR
VOX
VOX
DD
Convenient functions for transmit
