■ ACC set mode
12-7
12
SET MODE
Sets the desired audio output level, output from
[ACC1], within 0 to 100% in 1% steps.
• Outputs approx. 200 mV at 50% (default) setting.
ACC AF Output Level
50
%
Sets the desired output level of [S/P DIF], within 0 to
100% in 1% steps. (default: 100%)
S/PDIF Output Level
100
%
Sets the desired audio input level for modulation from
[ACC1].
• Approx. 100 mV at 50% (default) setting.
ACC MOD Level
50
%
Sets the desired input level for modulation from
[S/P DIF], within 0 to 100% in 1% steps.
(default: 50%)
S/PDIF MOD Level
50
%
Selects the desired connector(s) for modulation input
when data mode is not in use.
• MIC : Use the signals from [MIC].
• ACC : Use the signals from [ACC1] (pin 4).
• MIC,ACC : Use the signals from [MIC] and [ACC1]
(pin 4). (default)
• S/P DIF : Use the signals from [S/P DIF].
DATA OFF MOD
MIC,ACC
Selects the desired connector(s) for modulation input
when data 1 mode (D1) is in use.
• MIC : Use the signals from [MIC].
• ACC : Use the signals from [ACC1] (pin 4).
(default)
• MIC,ACC : Use the signals from [MIC] and [ACC1]
(pin 4).
• S/P DIF : Use the signals from [S/P DIF].
DATA1 MOD
ACC
Selects the desired connector(s) for modulation input
when data 2 mode (D2) is in use.
• MIC : Use the signals from [MIC].
• ACC : Use the signals from [ACC1] (pin 4).
• MIC,ACC : Use the signals from [MIC] and [ACC1]
(pin 4). (default)
• S/P DIF : Use the signals from [S/P DIF].
DATA2 MOD
MIC,ACC
