Icom IC-7700 [71/216] D rtty decode set mode continued
![Icom IC-7700 [71/216] D rtty decode set mode continued](/views2/1074139/page71/bg47.png)
4-19
DD
RTTY decode set mode (continued)
4
RECEIVE AND TRANSMIT
Explicitly inserts the FIGS character even though it is
not required by the receiving station.
•ON: Inserts FIGS.
• OFF : Does not insert FIGS.
RTTY TX USOS
ON
Turn the time stamp (date, transmission or reception
time) indication ON and OFF.
•ON: Displays the time stamp.
• OFF : No time stamp indication.
Selects the clock indication for time stamp usage.
NOTE: The time won’t be displayed when “OFF” is
selected in “RTTY Time Stamp” as above.
• Local : Selects the time that set in “Time (Now).”
• UTC* : Selects the time that set in “CLOCK2.”
*The name of choice may differ according to
“CLOCK2 Name” setting (p. 11-2). “UTC” is the
default name of CLOCK2.
RTTY Time Stamp
ON
RTTY Time Stamp (Time)
Local
Selects the automatic new line code (CR+LF) trans-
mission capability.
•ON: Transmits CR+LF code once.
• OFF : Transmits no CR+LF code.
RTTY Auto CR+LF by TX
ON
Set the text color for transmitted characters.
• The color is set in RGB format.
• The set color is indicated in the box beside the RGB scale.
• Push [Ω≈] to select R (Red), G (Green) and B (Blue),
and then rotate the main dial to set the ratio from 0 to 255.
F-3
RTTY Font Color (Transmit)
255 106 106
Selects the operating frequency indication for time
stamp usage.
NOTE: The frequency won’t be displayed when “OFF”
is selected in “RTTY Time Stamp” as above.
•ON: Displays the operating frequency.
• OFF : No operating frequency display.
Set the text color for received characters.
• The color is set in RGB format.
• The set color is indicated in the box beside the RGB scale.
• Push [Ω≈] to select R (Red), G (Green) and B (Blue),
and then rotate the main dial to set the ratio from 0 to 255.
F-3
RTTY Time Stamp (Frequency)
OFF
RTTY Font Color (Receive)
128 255 128
Set the text color for time stamp indication.
• The color is set in RGB format.
• The set color is indicated in the box beside the RGB scale.
• Push [Ω≈] to select R (Red), G (Green) and B (Blue),
and then rotate the main dial to set the ratio from 0 to 255.
F-3
Set the text color in the TX buffer screen.
• The color is set in RGB format.
• The set color is indicated in the box beside the RGB scale.
• Push [Ω≈] to select R (Red), G (Green) and B (Blue),
and then rotate the main dial to set the ratio from 0 to 255.
F-3
RTTY Font Color (Time Stamp)
0 155 189
RTTY Font Color (TX Buffer)
255 255 255
