Scope set mode (continued)
5
FUNCTIONS FOR RECEIVE
Select the sweep speed for the ±50 kHz span selec-
tion from SLOW, MID and FAST.
(± 50k)
FAST
Select the sweep speed for the ±100 kHz span selec-
tion from SLOW, MID and FAST.
(± 100k)
FAST
Select the sweep speed for the ±250 kHz span selec-
tion from SLOW, MID and FAST.
(± 250k)
FAST
Set the scope edge frequencies for fixed mode for
bands below 1.6 MHz.
• Set the frequencies within 0.030 to 1.600 MHz
range in 1 kHz steps.
As edge frequencies are set, the other edge fre-
quency will be automatically set for a display
band width of 5 kHz to a maximum of 500 kHz.
Fixed Edges ( 0.03 – 1.60)
0.750 1.250– MHz
Set the scope edge frequencies for fixed mode scope
when the 1.6 to 2 MHz band is selected.
• Set the frequencies within 1.600 to 2.000 MHz
range in 1 kHz steps.
( 1.60 – 2.00)
1.800 2.000– MHz
Set the scope edge frequencies for fixed mode scope
when the 2 to 6 MHz band is selected.
• Set the frequencies within 2.000 to 6.000 MHz
range in 1 kHz steps.
As edge frequencies are set, the other edge fre-
quency will be automatically set for a display
band width of 5 kHz to a maximum of 500 kHz.
( 2.00 – 6.00)
3.500 4.000– MHz
Set the scope edge frequencies for fixed mode scope
when the 6 to 8 MHz band is selected.
• Set the frequencies within 6.000 to 8.000 MHz
range in 1 kHz steps.
As edge frequencies are set, the other edge fre-
quency will be automatically set for a display
band width of 5 kHz to a maximum of 500 kHz.
( 6.00 – 8.00)
7.000 7.300– MHz
Select the sweep speed for the ±25 kHz span selec-
tion from SLOW, MID and FAST.
(± 25k)
FAST
