Icom IC-7700 [165/216] Display set mode
![Icom IC-7700 [165/216] Display set mode](/views2/1074139/page165/bga5.png)
12-11
12
SET MODE
Select “ON” when the external display is connected.
(default: OFF)
• At least 800×600 pixel resolution is required for the dis-
play.
External Display
OFF
Selects the suitable pulse level for the connected ex-
ternal display from H and L. (default: H)
External Display Sync Pulse
H
Turns the opening message screen indication capa-
bility ON and OFF. (default: ON)
Opening Message
ON
■ Display set mode (continued)
Turns the screen saver function ON (15, 30 or 60
minutes) and OFF. (default: 60 min.)
The screen saver will activate when no operation is
performed for the selected time period to protect the
LCD from the “burn-in” effect.
Screen Saver Function
60min
Selects the screen saver type from “Bound,” “Rota-
tion” and “Twist.” (default: Bound)
The screen saver indication can be displayed for your
reference while pushing and holding [PREVIEW] .
F-5
Screen Saver Type
Bound
Sets the introductory text, up to 10-character long,
displayed in the opening screen.
Usually, you set your call sign for the opening screen.
Capital letters, small letters, numerals, some symbols
(– / . @) and spaces can be used.
z Push [EDIT] to select the name edit condition.
• The cursor under the 1st character blinks.
x Push [ABC] (MF6), [abc] (MF6), [123] (MF7) or
[Symbol] (MF7) to select the character group, then
rotate the main dial to select the character.
•Push [ABC] (MF6) or [abc] (MF6) to toggle capital and
small letters.
• Push [123]
(MF7) or [Symbol] (MF7) to toggle numerals
and symbols.
• Push [Ω] or [≈] for cursor movement.
• Push [DEL] to delete the selected character.
• Push [SPACE] to input a space.
• Pushing the transceiver’s keypad, [0]–[9], can also
enter numerals.
c Push to set the name.
EXIT/SET
F-4
F-3
F-2F-1
F-5
My Call
