![Icom IC-7700 [175/216] D load option set mode](/views2/1074139/page175/bgaf.png)
12-21
12
SET MODE
DD
Load option set mode
Selects file load condition from All and Select.
(default: Select)
• All : Loads and sets the all following contents.
• Select : Loads and sets the selected contents only.
Load Contents
Select
Selects the antenna memory setting loading condition
from YES and NO. (default: NO).
• YES : Loads and sets the antenna memory.
•NO: Use the original antenna memory setting.
ANT Memory
NO
Selects the reference signal setting load condition
from YES and NO. (default: NO).
• YES : Loads and sets the reference signal setting.
•NO: Use the original reference signal setting.
REF IN/OUT, REF Adjust
NO
Selects the IP address and subnet mask setting load
condition from YES and NO. (default: NO).
• YES : Loads and sets the IP address and subnet
mask setting.
•NO: Use the original IP address and subnet
mask setting.
IP Address, Subnet Mask
NO
Selects the CI-V address setting load condition from
YES and NO. (default: NO).
• YES : Loads and sets the CI-V address setting.
•NO: Use the original CI-V address setting.
CI–V Address
NO
This setting is fixed “YES.” • YES : Loads and sets memory channel contents
and other settings.
Other Memory & Settings
YES
Selects the voice TX message load condition from
YES and NO. (default: YES).
• YES : Loads and sets voice TX message.
•NO: Use the original voice TX message.
Voice TX Memory
YES
Selects the voice RX message load condition from
YES and NO. (default: NO).
• YES : Loads and sets voice RX message.
•NO: Use the original voice RX message.
Voice RX Memory
NO
