5-8
DD
Scope set mode (continued)
5
FUNCTIONS FOR RECEIVE
Set the scope edge frequencies for fixed mode scope
when the 30 to 45 MHz band is selected.
• Set the frequencies within 30.000 to 45.000 MHz
range in 1 kHz steps.
As edge frequencies are set, the other edge fre-
quency will be automatically set for a display
band width of 5 kHz to a maximum of 500 kHz.
(30.00 – 45.00)
30.000 30.500– MHz
Set the scope edge frequencies for fixed mode scope
when the 45 to 60 MHz band is selected.
• Set the frequencies within 45.000 to 60.000 MHz
range in 1 kHz steps.
As edge frequencies are set, the other edge fre-
quency will be automatically set for a display
band width of 5 kHz to a maximum of 500 kHz.
(45.00 – 60.00)
50.000 50.500– MHz
Set the scope edge frequencies for fixed mode scope
when the 26 to 30 MHz band is selected.
• Set the frequencies within 26.000 to 30.000 MHz
range in 1 kHz steps.
As edge frequencies are set, the other edge fre-
quency will be automatically set for a display
band width of 5 kHz to a maximum of 500 kHz.
(26.00 – 30.00)
28.000 28.500– MHz
