Si-71A Troubleshooting by Remote Controller Display / LED Display
Troubleshooting 115
6.17 Malfunction of Discharge Pipe Temperature Sensor System
Remote Controller
Display
-6
-6-6
-6
Outdoor Unit LED
Display
A(H1P)
ñ
1(H2P)
ò
2(H3P)
ò
Applicable Models
R(Y)
Malfunction
Decision
Conditions
Case where the discharge pipe temperature sensor has a short or open circuit
Supposed Causes
„
Failure of discharge pipe temperature sensor
„
Failure of discharge pipe temperature sensor’s connector connection
„
Failure of outdoor unit PC board
Troubleshooting
Note:
Measure the resistance while referring to the thermistor temperature and resistance conversion table.
Thermistor temperature and resistance conversion table.
Disconnect the
discharge pipe
temperature
sensor(R3T) from
X6A on the outdoor
unit PC board and
measure the
resistance.
Is
the thermistor
normal?
(See note)
NO
YES
Dischange pipe
temperature sensor
rep;acement
If contact is OK,
replace outdoor unit
PC board.
(SF019)
Temperature Discharge pipe sensor(k
Ω
) Temperature Discharge pipe sensor(k
Ω
)
-6.0 866.8 28.0 175.8
-4.0 782.7 30.0 161.5
-2.0 707.6 32.0 148.4
0.0 640.4 34.0 136.6
2.0 579.9 36.0 125.8
4.0 525.6 38.0 115.3
6.0 477.0 40.0 106.5
8.0 433.4 42.0 98.8
10.0 394.2 44.0 91.3
12.0 358.9 46.0 84.4
14.0 327.1 48.0 78.1
16.0 298.5 50.0 72.3
18.0 272.6 52.0 67.1
20.0 249.2 54.0 62.2
22.0 228.1 56.0 57.8
24.0 208.9 58.0 53.7
26.0 191.5
