For R(Y)71K Si-71A
188 Removal Procedure
6.7 Removal of Compressor
Procedure
Warning Be sure to turn off all power supplies before disassembling work.
Step Procedure Points
∗
Remove the external casing, etc.,
according to its removal procedure.
1 Remove the compressor
sound-proofing.
2 Disconnect the compressor
lead wire from the
compressor terminal.
Remove the solenoid valve
coil.
3 Heat the brazed parts of the
discharge and suction pipes,
and remove from the piping
side with a pair of pliers, etc.
