Si-71A For FHY71F
Removal Procedure 151
8 Lower the front surface of
the drain pan, remove the
hooking part of the rear
surface, and remove the
drain pan.
(1) Lower the front surface of the drain
pan.
(2) Remove the hooking part of the
rear surface.
Step Procedure Points
