Si-71A Present Model’s Functions
Improved Points and Functions 5
O
: Improved Points and Functions
{
: Holding Functions
—
: No Functions
Items Improved Points and Functions Ceiling Mounted Built-in Ceiling Mounted
Cassette Corner
Wall
Mounted
Floor
Standing
35~60 71~125 35~60 71 71, 100 71~125
Model type Indoor Units Present Present Present Present Present Present
Outdoor Units New New New New New New
Main
Improvement
(Indoor Unit)
Appearance Improved — — — — — —
Reduction of Dimensions or Weight — — — — — —
Reduction of Operation Sound — — — — — —
For Comfortable
Air Conditioning
Auto Restart
{{{{{{
Fan Operation Mode
{{{{{{
LCD Remote Controller (Option)
(LCD = Liquid Crystal Display)
{{{{{{
Auto Swing Function — —
{{{{
Ceiling Soiling Prevention — —
{{
——
Program Dry
{{{{{{
High Fan Speed Mode — — — —
{
—
High Ceiling Application — —
{{
——
Low Ambient Temperature Kit (Option) —
{
—
{{{
Timer Selector
{{{{{{
For Easy
Construction and
Maintenance
Drain Pump Kit
{{{{
——
Urtra Long Life Filter — — — — — —
Long Life Filter
{{{{
——
Mold Resistant Treatment for Filter
{{{{{{
Filter Sign
{{{{{{
Mold Resistant Drain Pan
{{{{{
—
Emergency Operation
{{{{{{
Self Diagnoses Function
{{{{{{
For Flexible
Control
Double Remote Control
{{{{{{
Group Control by 1 Remote Controller
{{{{{{
Cotnrol by External Command
{{{{{{
Remote/Centralized Control
{{{{{{
