Daikin FHYB45FV1 [157/244] Removal of fan rotor an motor
![Daikin FHYB125FVAL [157/244] Removal of fan rotor an motor](/views2/1764299/page157/bg9d.png)
For FHY71F Si-71A
146 Removal Procedure
2.4 Removal of Fan Rotor an Motor
Procedure
Warning Be sure to turn off all power supplies before disassembling work.
Step Procedure Points
1 Push the 2 tabs of the fan
housing toward the inside
with your fingers, and pull
out the fan housing.
2 Loosen the 2 hexagon set
screws of the intermediate
bearing.
