Si-71A Troubleshooting Based on Equipment Condition
Troubleshooting 81
3. Troubleshooting Based on Equipment Condition
3.1 Troubleshooting Based on Equipment Condition
Equipment Condition Remedy
1 Equipment does not operate. See page 82
2 Fan operates, but compressor does not. See page 83
3 Cooling/heating operation starts but stops
immediately.
See page 84
4 After equipment shuts down, it cannot be
restarted for a while.
See page 85
5 Equipment operates but does not provide
cooling.
See page 86
6 Equipment operates but does not provide
heating.
See page 87
7 Equipment discharges white mist. See page 88
8 Equipment produces loud noise or shakes. See page 89
9 Equipment discharges dust. See page 90
10 Remote controller LCD displays “88.” See page 91
11 Equipment emits odor. Room smell and cigarette odors accumulated
inside the indoor unit are discharged with air.
Inside of the indoor unit must be cleaned.
12 Flap operates when power is turned on. It is normal. The flap initializes for accurate
positioning.
13 Change of operation mode causes flap to move. It is normal. There is a control function that
moves the flap when operation mode is
changed.
14 Fan operates in “M” mode during heating even if
remote controller is set to “Low.”
It is normal. It is caused by the activation of the
overload control (airflow shift control).
15 Flap automatically moves during cooling. It is normal. It is caused by the activation of the
dew prevention function or ceiling dirtiness
reducing function.
16 Indoor unit fan operates in “L” mode for 1 minute
in microcomputer-controlled dry mode even if
compressor is not operating.
It is normal. The monitoring function forcibly
operates the fan for one minute.
17 In simultaneous ON/OFF multi-system setup,
indoor unit (slave) does not operate in sync with
the other indoor unit (master). (Flat, fan, etc.)
It is normal. It is caused by a signal transmission
lag.
18 Indoor unit fan operates after heating operation
stops.
It is normal. The fan operates in the “LL” mode
for 60 to 100 seconds to dissipate the residual
heat in the heater.
19 Drain pump operates when equipment is not
operating.
It is normal. The drain pump continues to
operate for several minutes after equipment is
turned off.
20 Horizontal wing sends air to different directions
in cooling and heating even if it is set to the same
position.
It is normal. The airflow direction in cooling/dry
operation is different from that in heating/
ventilation operation.
21 Flap remains horizontal even if it is set to Swing. It is normal. The flap does not swing in the
thermostat OFF mode.
