Electric Function Parts Si-71A
58 Explanation of Function Operation
R
∗
Figures inside parentheses are for E unit (anti-corrosion specifications).
R71KY1(E) R71KV1(E) R100KY1(E) R100KV1(E)
M1C Compressor JT90BC-YE JT90BC-V1 JT118BC-YE JT118BC-V1
J1HC Crank Case Heater 33W
S1PH Pressure Switch for Maintaining
High Pressure
ACB-DB82
OFF : 30
+0
-1
(kg/cm²G)
ON : 22
±
1.5 (kg/cm²G)
S1LP Pressure Switch for Low
Pressure Control
20PS-1164-1
OFF : –23
±
15 (cmHg)
ON : 0.5
±
0.3 (kg/cm²G)
K1M Magnetic Switch HOE-20F-TRA1 HOE-26F-TRA1 HOE-20F-TRA1 HOE-26F-TRA1
F1C Overcurrent Relay 7.5A 22A 10A 33A
M1F Outdoor Unit Fan (Upper) 70W 90W
M2F Outdoor Unit Fan (Lower) — 65W
Q1L
Q2L
Outdoor Unit Fan Motor Safety
Thermostat
OFF : 135
±
5°C
ON : Below 120°C
C1R Capacitor for M1F 6
µ
F
C2R Capacitor for M2F — 6
µ
F
A1P Outdoor Unit Control PC Board
∗
EC9524 (EC9534) EC9523 (EC9533) EC9528 (EC9538) EC9527 (EC9537)
A2P Outdoor Control PC Board
(Models for the FJ Type Only)
—
R1T Thermistor (for Outdoor Air) ST9303
R2T Thermistor (for Heat Exchanger) ST8604A
R3T Thermistor (for Discharge Pipe) ST8606
T1R Transformer TR21H16R2
Y1E Electronic Expansion Valve DKV18D93 (Main unit) EKV24D34 (Main unit) EKV24D34
DKV-MOZS130BO (Coil) EKV-MOZS107B0 (Coil)
K1S Starting Relay — CLK-15J02-P15 — CLK-15J02-P14
C3R,
C4R
M1C Capacitor — 46
µ
F+23
µ
F—46
µ
F+23
µ
F
C5R Starting Capacitor — 50
µ
F—75
µ
F
