For FUY71/100/125FJ Si-71A
162 Removal Procedure
3.8 Removal of Air Flow Control Blade
Procedure
Warning Be sure to turn off all power supplies before disassembling work.
Step Procedure Points
1. To remove horizontal blade,
press down tabs located at
both end of blade and pull
them forward.
2. Remove horizontal blade.
