Si-71A For FHY71F
Removal Procedure 149
2.6 Removal of Bottom Panel and Drain Pan
Procedure
Warning Be sure to turn off all power supplies before disassembling work.
Step Procedure Points
∗
Remove the air filter according to
its removal procedure.
1 Remove the right side panel
installation screw.
2 Slide the right side panel
toward the front of the unit
and remove.
3 Remove the 2 wiring cover
installation screws.
4 Remove the wiring cover.
