Si-71A Troubleshooting Based on Equipment Condition
Troubleshooting 83
3.3 Fan Operates, but Compressor does not.
Applicable Model
All models of Skyair series
Error Detection
Method
Error Generating
Condition
Possible Causes
„
Faulty remote controller
„
Faulty magnetic switch for compressor
Troubleshooting
Make the following
temperature setting using
remote controller.
(1) Cooling: Lowest setting
(2) Heating: Highest setting
Possibly faulty electric
components
Normal.
Diagnose based on error code on
remote controller.
Equipment cannot be operated in this
condition.
Check electric components.
Does
equipment operate?
Is
operation lamp
on remote controller
flashing?
Is outside
temperature above
allowed operating
range?
Is operation
lamp on indoor unit
located near wireless
remote controller signal
receiving section
flashing?
YES
NO
NO
NO
NO
YES
YES
YES
(SF032)
