Electric Function Parts Si-71A
54 Explanation of Function Operation
FAY~F
FAY~FA
FVY~F
Drawing No. given inside brackets[ ].
FVY~L
Drawing No. given inside brackets[ ].
Capacity 71 100 Remarks
Wired Remote Controller BRC1B51·61 (EC9505) Optional
Accessory
Electronic Control Unit EC9654
Fan Motor 4P 46W 4P 49W
Fan Motor Capacitor 2
µ
F
Swing Flap Motor
(with Limit Switch)
MT8 [3SB40350-1]
Capacity 71 100 Remarks
Wired Remote Controller BRC1B51·61 (EC9505) Optional
Accessory
Electronic Control Unit EC9905
Fan Motor 4P 37W 4P 46W
Fan Motor Capacitor 1.5
µ
F
Swing Flap Motor
(with Limit Switch)
MT8 [3SB40350-1]
Capacity 71 100 125 Remarks
Control Panel BRC1B61(EC9505)
Electronic Control Unit EC9517
Fan Motor
(Temperature
Protector
120°C)
Upper V1:AP-NOT
6P 13W
VAL:AP-NOT
6P 13W
V1:AP-NOT
6P 27W
VAL:AP-NOT
6P 27W
V1:AP-NOT
6P 27W
VAL:AP-NOT
6P 27W
Lower V1:AP-NOT
6P 20W
VAL:AP-NOT
6P 20W
V1:AP-NOT
6P 27W
VAL:AP-NOT
6P 27W
V1:AP-NOT
6P 56W
VAL:AP-NOT
6P 56W
Fan Motor
Capacitor
Upper 2.5
µ
F4
µ
F4
µ
F
Lower 3
µ
F4
µ
F6
µ
F
Swing Motor MT8-L [3PA07279-1]
Capacity 71 100 125 Remarks
Control Panel BRC1B61(EC9505)
Electronic Control Unit FVY:EC98115 FV:EC98114
Fan Motor (Temperature
Protector 130°C)
AP-NOT
6P 30W
AP-NOT
6P 60W
AP-NOT
6P 90W
Fan Motor Capacitor 7
µ
F8
µ
F
Swing Motor MT8-L [3P027592-1]
