Chapter 9 VLAN
MES-3728 User’s Guide
110
9.10 Create an IP-based VLAN Example
This example shows you how to create an IP VLAN which includes ports 1, 4 and
8. Follow these steps:
1 Activate this protocol based VLAN.
2 Type the port number you want to include in this protocol based VLAN. Type 1.
3 Give this protocol-based VLAN a descriptive name. Type IP-VLAN.
4 Select the protocol. Leave the default value IP.
5 Type the VLAN ID of an existing VLAN. In our example we already created a static
VLAN with an ID of 5. Type 5.
Add Click Add to save your changes to the Switch’s run-time memory. The
Switch loses these changes if it is turned off or loses power, so use the
Save link on the top navigation panel to save your changes to the non-
volatile memory when you are done configuring.
Cancel Click Cancel to begin configuring this screen afresh.
Index This is the index number identifying this protocol based VLAN. Click on any
of these numbers to edit an existing protocol based VLAN.
Active This field shows whether the protocol based VLAN is active or not.
Port This field shows which port belongs to this protocol based VLAN.
Name This field shows the name the protocol based VLAN.
Ethernet
Type
This field shows which Ethernet protocol is part of this protocol based
VLAN.
VID This field shows the VLAN ID of the port.
Priority This field shows the priority which is assigned to frames belonging to this
protocol based VLAN.
Delete Click this to delete the protocol based VLANs which you marked for
deletion.
Cancel Click Cancel to begin configuring this screen afresh.
Table 19 Advanced Application > VLAN > VLAN Port Setting > Protocol Based
VLAN Setup (continued)
LABEL DESCRIPTION
