Chapter 3 Hardware Overview
MES-3728 User’s Guide
34
3.1.1 Console Port
For local management, you can use a computer with terminal emulation software
configured to the following parameters:
• VT100
• Terminal emulation
• 9600 bps
• No parity, 8 data bits, 1 stop bit
• No flow control
Connect the male 9-pin end of the console cable to the console port of the Switch.
Connect the female end to a serial port (COM1, COM2 or other COM port) of your
computer.
3.1.2 Gigabit Ethernet Ports
The Switch has 1000Base-T auto-negotiating, auto-crossover Ethernet ports. In
10/100/1000 Mbps Fast Ethernet, the speed can be 10 Mbps, 100 Mbps or 1000
Mbps and the duplex mode can be half duplex or full duplex.
An auto-negotiating port can detect and adjust to the optimum Ethernet speed
(10/100/1000 Mbps) and duplex mode (full duplex or half duplex) of the
connected device.
Two Dual
Personality
Interfaces
Each interface has one 1000BASE-T RJ-45 port and one Small Form-Factor
Pluggable (SFP) slot (also called a mini-GBIC slot), with one port or
transceiver active at a time.
• Two 100/1000 Mbps RJ-45 Ports:
Connect these ports to high-bandwidth backbone network Ethernet
switches using 1000BASE-T compatible Category 5/5e/6 copper cables.
•Two Mini-GBIC Slots:
Use mini-GBIC transceivers in these slots for connections to backbone
Ethernet switches.
Console Port The console port is for local configuration of the Switch.
Management
Port
Connect to a computer using an RJ-45 Ethernet cable for local
configuration of the Switch.
Signal Connect the signal input pins to signal output terminals on other pieces of
equipment.
Connect the signal output pins to a signal input terminal on another piece
of equipment.
See Chapter 42 on page 359 for details on the pin assignments required.
Table 1 Front Panel Connections (continued)
LABEL DESCRIPTION
