Chapter 4 The Web Configurator
MES-3728 User’s Guide
52
Layer 2
Protocol
Tunneling
This link takes you to a screen where you can configure L2PT (Layer 2
Protocol Tunneling) settings on the Switch.
IP Application
Static Routing This link takes you to a screen where you can configure static routes. A
static route defines how the Switch should forward traffic by configuring
the TCP/IP parameters manually.
DiffServ This link takes you to screens where you can enable DiffServ, configure
marking rules and set DSCP-to-IEEE802.1p mappings.
DHCP This link takes you to screens where you can configure the DHCP
settings.
Management
Maintenance This link takes you to screens where you can perform firmware and
configuration file maintenance as well as reboot the system.
Access Control This link takes you to screens where you can change the system login
password and configure SNMP and remote management.
Diagnostic This link takes you to a screen where you can view system logs and test
port(s).
Syslog This link takes you to screens where you can setup system logs and a
system log server.
Cluster
Management
This link takes you to screens where you can configure clustering
management and view its status.
MAC Table This link takes you to a screen where you can view the MAC addresses
(and types) of devices attached to what ports and VLAN IDs.
ARP Table This link takes you to a screen where you can view the MAC addresses –
IP address resolution table.
Configure
Clone
This link takes you to a screen where you can copy attributes of one port
to other ports.
Table 4 Navigation Panel Links (continued)
