Chapter 35 Diagnostic
MES-3728 User’s Guide
328
The following table describes the labels in this screen.
Table 113 Management > Diagnostic
LABEL DESCRIPTION
System Log Click Display to display a log of events in the multi-line text box.
Click Clear to empty the text box and reset the syslog entry.
IP Ping Type the IP address of a device that you want to ping in order to test a
connection.
Click Ping to have the Switch ping the IP address (in the field to the
left).
Ethernet Port
Test
Enter a port number and click Port Test to perform an internal
loopback test.
