Zyxel MES-3728 [360/388] Table 124 hardware specifications
![Zyxel MES-3728 [360/388] Table 124 hardware specifications](/views2/1010861/page360/bg168.png)
Chapter 42 Product Specifications
MES-3728 User’s Guide
360
LEDs Per switch: BPS, PWR, SYS, ALM
Per Fast Ethernet RJ-45 10/100 port: LNK/ACT
Per mini-GBIC slot: LNK, ACT
Per 1000BASE-T RJ-45 port (in dual personality interface): LNK/
ACT, FDX
Per Management port: 10, 100
Operating
Environment
Temperature: 0ºC ~ 65ºC (32ºF ~ 149ºF)
Humidity: 10 ~ 90% (non-condensing)
Storage Environment Temperature: -10º C ~ 70º C (14º F ~ 158º F)
Humidity: 10 ~ 90% (non-condensing)
Ground Wire Gauge 18 AWG or larger
Power Wire Gauge 18 AWG or larger
Fuse Specification 250 VAC, T2A
External Signal Jack Supports input from four external alarms or other devices and
output to one device.
External Signal
connector
• Input: connect any one of the input pin pairs (4,5) (6,7) (8,9)
(10,11) to a normally open (NO) dry contact device without
any external input power. An alarm is triggered when the
circuit is closed.
• Output: dry contact (support 20 VDC, 500mA only), connect
the output pin pair (1,2) to a device in Normal Close (NO)
operation and/or pin pair (2,3) to a device in Normal Open
(NO) operation.
Standard Wire Gauge: 20 ~ 28 AWG
Wire strip length: 6 ~7 mm
Table 125 Firmware Specifications
FEATURE DESCRIPTION
Default IP Address In band: 192.168.1.1
Out of band (Management port): 192.168.0.1
Default Subnet Mask 255.255.255.0 (24 bits)
Administrator User
Name
admin
Default Password 1234
Number of Login
Accounts Configurable
on the Switch
4 management accounts configured on the Switch.
Authentication via RADIUS and TACACS+ also available.
Maximum Frame Size 9 K (9216 bytes)
Table 124 Hardware Specifications
