Chapter 34 Access Control
MES-3728 User’s Guide
311
Table 107 SNMP Switch Traps
OPTION OBJECT LABEL OBJECT ID DESCRIPTION
stp STPNewRoot 1.3.6.1.2.1.17.0.1 This trap is sent when the STP
root switch changes.
MRSTPNewRoot 1.3.6.1.4.1.890.1.5.8.45.36.
2.1
This trap is sent when the
MRSTP root switch changes.
MSTPNewRoot 1.3.6.1.4.1.890.1.5.8.45.10
7.70.1
This trap is sent when the
MSTP root switch changes.
STPTopologyChange 1.3.6.1.2.1.17.0.2 This trap is sent when the STP
topology changes.
MRSTPTopologyChange 1.3.6.1.4.1.890.1.5.8.45.36.
2.2
This trap is sent when the
MRSTP topology changes.
MSTPTopologyChange 1.3.6.1.4.1.890.1.5.8.45.10
7.70.2
This trap is sent when the
MSTP root switch changes.
mactable MacTableFullEventOn 1.3.6.1.4.1.890.1.5.8.45.27.
2.1
This trap is sent when more
than 99% of the MAC table is
used.
MacTableFullEventClear 1.3.6.1.4.1.890.1.5.8.45.27.
2.2
This trap is sent when less
than 95% of the MAC table is
used.
rmon RmonRisingAlarm 1.3.6.1.2.1.16.0.1 This trap is sent when a
variable goes over the RMON
"rising" threshold.
RmonFallingAlarm 1.3.6.1.2.1.16.0.2 This trap is sent when the
variable falls below the RMON
"falling" threshold.
cfm dot1agCfmFaultAlarm 1.3.111.2.802.1.1.8.0.1 The trap is sent when the
Switch detects a connectivity
fault.
