Chapter 38 MAC Table
MES-3728 User’s Guide
342
• If the Switch has already learned the port for this MAC address, but the
destination port is the same as the port it came in on, then it filters the frame.
Figure 189 MAC Table Flowchart
38.2 Viewing the MAC Table
Click Management > MAC Table in the navigation panel to display the following
screen.
Figure 190 Management > MAC Table
