Zyxel MES-3728 [180/388] Viewing and editing classifier configuration
![Zyxel MES-3728 [180/388] Viewing and editing classifier configuration](/views2/1010861/page180/bgb4.png)
Chapter 20 Classifier
MES-3728 User’s Guide
180
20.3 Viewing and Editing Classifier
Configuration
To view a summary of the classifier configuration, scroll down to the summary
table at the bottom of the Classifier screen. To change the settings of a rule, click
a number in the Index field.
IP
Address/
Address
Prefix
Enter a source IP address in dotted decimal notation.
Specify the address prefix by entering the number of ones in the subnet mask.
A subnet mask can be represented in a 32-bit notation. For example, the
subnet mask “255.255.255.0” can be represented as
“11111111.11111111.11111111.00000000”, and counting up the number of
ones in this case results in 24.
Socket
Number
Note: You must select either UDP or TCP in the IP Protocol field before
you configure the socket numbers.
Select Any to apply the rule to all TCP/UDP protocol port numbers or select
the second option and enter a TCP/UDP protocol port number. Refer to Table
49 on page 182 for more information.
Destination
IP
Address/
Address
Prefix
Enter a destination IP address in dotted decimal notation.
Specify the address prefix by entering the number of ones in the subnet mask.
Socket
Number
Note: You must select either UDP or TCP in the IP Protocol field before
you configure the socket numbers.
Select Any to apply the rule to all TCP/UDP protocol port numbers or select
the second option and enter a TCP/UDP protocol port number. Refer to Table
49 on page 182 for more information.
Add Click Add to insert the entry in the summary table below and save your
changes to the Switch’s run-time memory. The Switch loses these changes if it
is turned off or loses power, so use the Save link on the top navigation panel
to save your changes to the non-volatile memory when you are done
configuring.
Cancel Click Cancel to reset the fields back to your previous configuration.
Clear Click Clear to set the above fields back to the factory defaults.
Table 45 Advanced Application > Classifier (continued)
LABEL DESCRIPTION
