Zyxel MES-3728 [149/388] Bandwidth control continued
![Zyxel MES-3728 [149/388] Bandwidth control continued](/views2/1010861/page149/bg95.png)
Chapter 14 Bandwidth Control
MES-3728 User’s Guide
149
Active Select this check box to activate egress rate limits on this port.
Egress Rate Specify the maximum bandwidth allowed in kilobits per second (Kbps) for
the out-going traffic flow on a port.
Apply Click Apply to save your changes to the Switch’s run-time memory. The
Switch loses these changes if it is turned off or loses power, so use the
Save link on the top navigation panel to save your changes to the non-
volatile memory when you are done configuring.
Cancel Click Cancel to reset the fields.
Table 33 Advanced Application > Bandwidth Control (continued)
LABEL DESCRIPTION
