Chapter 21 Policy Rule
MES-3728 User’s Guide
187
Click Advanced Applications > Policy Rule in the navigation panel to display
the screen as shown.
Figure 95 Advanced Application > Policy Rule
The following table describes the labels in this screen.
Table 50 Advanced Application > Policy Rule
LABEL DESCRIPTION
Active Select this option to enable the policy.
Name Enter a descriptive name for identification purposes.
