![Zyxel MES-3728 [359/388] Product specifications](/views2/1010861/page359/bg167.png)
MES-3728 User’s Guide
359
CHAPTER 42
Product Specifications
The following tables summarize the Switch’s hardware and firmware features.
Table 124 Hardware Specifications
SPECIFICATION DESCRIPTION
Dimensions Standard 19” rack mountable
438 mm (W) x 215 mm (D) x 44.45 mm (H)
Weight 3.4 kg
Power Specification One Backup Power Supply (BPS) connector
AC: 100-240 VAC, 50/60 Hz, 0.5 A Max.
DC: -36 VDC ~ -72 VDC, 0.7 A Max.
Note: There is no tolerance for the DC input voltage.
Power Consumption AC: 24 W (maximum)
DC: 27 W (maximum)
Interfaces 24 10/100 Base-Tx ports
2 GbE Dual Personality interfaces (Each interface has one
1000Base-T RJ-45 port and one Small Form-Factor Pluggable
(SFP) slot, with one port active at a time.)
2 mini-GBIC (SFP) slots
One local management 100Base-T RJ-45 port
Auto-negotiation
Auto-MDIX
One console port
Compliant with IEEE 802.3ad/u/x
Back pressure flow control for half duplex
Flow control for full duplex (IEEE 802.3x)
External alarm jack
