Chapter 42 Product Specifications
MES-3728 User’s Guide
364
VLAN Port-based VLAN
802.1Q tag-based VLAN
number of VLAN: 4K, 2000 static maximum
GVRP for dynamic registration
Double tagging for VLAN stacking
Private VLAN for port isolation.
Protocol-Based VLAN.
IP subnet based VLAN
VLAN mapping
Port
Aggregation
IEEE 802.3ad LACP
Six groups (up to eight ports each)
Port
mirroring
Rule-based port mirroring
Port-based mirroring
Support port mirroring per IP/TCP/UDP
Bandwidth
control
Supports rate limiting at 64 Kb increments
TRTCM
Provider
Bridge
BPDU transparency
Layer2 protocol tunneling
Layer 3
Features
IP
Capability
IPv4 support
64 IPv4Management IPs
Routing
protocols
Static Routing
IP services DHCP client
DHCP relay
VLAN-based DHCP relay
DHCP snooping
Filtering Support L2 MAC filtering, L3 IP filtering, Layer 4 TCP/UDP socket
Table 126 Feature Specifications (continued)
