Zyxel MES-3728 [120/388] Configuring static multicast forwarding
![Zyxel MES-3728 [120/388] Configuring static multicast forwarding](/views2/1010861/page120/bg78.png)
Chapter 11 Static Multicast Forward Setup
MES-3728 User’s Guide
120
Figure 60 Static Multicast Forwarding to A Single Port
Figure 61 Static Multicast Forwarding to Multiple Ports
11.2 Configuring Static Multicast Forwarding
Use this screen to configure rules to forward specific multicast frames, such as
streaming or control frames, to specific port(s).
Click Advanced Application > Static Multicast Forwarding to display the
configuration screen as shown.
Figure 62 Advanced Application > Static Multicast Forwarding
