Chapter 8 Basic Setting
MES-3728 User’s Guide
88
The following table describes the labels in this screen.
Table 11 Basic Setting > IP Setup
LABEL DESCRIPTION
Domain Name
Server
DNS (Domain Name System) is for mapping a domain name to its
corresponding IP address and vice versa. Enter a domain name server
IP address in order to be able to use a domain name instead of an IP
address.
Default
Management
Specify which traffic flow (In-band or Out-of-band) the Switch is to
send packets originating from itself (such as SNMP traps) or packets
with unknown source.
Select Out-of-band to have the Switch send the packets to the out-
of-band management port. This means that device(s) connected to
the other port(s) do not receive these packets.
Select In-band to have the Switch send the packets to all ports
except the out-of-band management port to which connected
device(s) do not receive these packets.
In-Band Management IP Address
DHCP Client Select this option if you have a DHCP server that can assign the
Switch an IP address, subnet mask, a default gateway IP address and
a domain name server IP address automatically.
Static IP Address Select this option if you don’t have a DHCP server or if you wish to
assign static IP address information to the Switch. You need to fill in
the following fields when you select this option.
IP Address Enter the IP address of your Switch in dotted decimal notation for
example 192.168.1.1.
IP Subnet Mask Enter the IP subnet mask of your Switch in dotted decimal notation
for example 255.255.255.0.
Default Gateway Enter the IP address of the default outgoing gateway in dotted
decimal notation, for example 192.168.1.254.
VID Enter the VLAN identification number associated with the Switch IP
address. This is the VLAN ID of the CPU and is used for management
only. The default is "1". All ports, by default, are fixed members of
this "management VLAN" in order to manage the device from any
port. If a port is not a member of this VLAN, then users on that port
cannot access the device. To access the Switch make sure the port
that you are connected to is a member of Management VLAN.
Out-of-band Management IP Address
IP Address Enter the IP address of your Switch in dotted decimal notation for
example 192.168.0.1.
If you change this IP address, make sure the computer connected to
this management port is in the same subnet before accessing the
Switch.
Subnet Mask Enter the IP subnet mask of your Switch in dotted decimal notation
for example 255.255.255.0.
Default Gateway Enter the IP address of the default outgoing gateway in dotted
decimal notation, for example 192.168.0.254.
