Chapter 20 Classifier
MES-3728 User’s Guide
178
Click Advanced Application > Classifier in the navigation panel to display the
configuration screen as shown.
Figure 92 Advanced Application > Classifier
The following table describes the labels in this screen.
Table 45 Advanced Application > Classifier
LABEL DESCRIPTION
Active Select this option to enable this rule.
Name Enter a descriptive name for this rule for identifying purposes.
