Zyxel MES-3728 [309/388] Table 103 snmp system traps continued
![Zyxel MES-3728 [309/388] Table 103 snmp system traps continued](/views2/1010861/page309/bg135.png)
Chapter 34 Access Control
MES-3728 User’s Guide
309
intrusionlo
ck
IntrusionLockEventOn 1.3.6.1.4.1.890.1.5.8.45.2
7.2.1
This trap is sent when intrusion
lock occurs on a port.
loopguard LoopguardEventOn 1.3.6.1.4.1.890.1.5.8.45.2
7.2.2
This trap is sent when
loopguard shuts down a port.
externalar
m
ExternalAlarmEventOn 1.3.6.1.4.1.890.1.5.8.45.2
7.2.1
This trap is sent when the
external alarm is received.
ExternalAlarmEventClear 1.3.6.1.4.1.890.1.5.8.45.2
7.2.2
This trap is sent when the
external alarm stops sending
an alert.
Table 103 SNMP System Traps (continued)
OPTION OBJECT LABEL OBJECT ID DESCRIPTION
Table 104 SNMP Interface Traps
OPTION OBJECT LABEL OBJECT ID DESCRIPTION
linkup linkUp 1.3.6.1.6.3.1.1.5.4 This trap is sent when the
Ethernet link is up.
LinkDownEventClear 1.3.6.1.4.1.890.1.5.8.45.27
.2.2
This trap is sent when the
Ethernet link is up.
linkdown linkDown 1.3.6.1.6.3.1.1.5.3 This trap is sent when the
Ethernet link is down.
LinkDownEventOn 1.3.6.1.4.1.890.1.5.8.45.27
.2.1
This trap is sent when the
Ethernet link is down.
autonegotiati
on
AutonegotiationFailedEve
ntOn
1.3.6.1.4.1.890.1.5.8.45.27
.2.1
This trap is sent when an
Ethernet interface fails to
auto-negotiate with the
peer Ethernet interface.
AutonegotiationFailedEve
ntClear
1.3.6.1.4.1.890.1.5.8.45.27
.2.2
This trap is sent when an
Ethernet interface auto-
negotiates with the peer
Ethernet interface.
lldp LLDPRemoteTopologyCha
nge
1.0.8802.1.1.2.0.0.1 This trap is sent when the
LLDP (Link Layer Discovery
Protocol) remote topology
changes.
transceiver-
ddmi
transceiverddmiEventOn 1.3.6.1.4.1.890.1.5.8.45.27
.2.1
This trap is sent when one
of the device operating
parameters (such as
transceiver temperature,
laser bias current,
transmitted optical power,
received optical power and
transceiver supply voltage)
is above or below a factory
set normal range.
transceiverddmiEventClea
r
1.3.6.1.4.1.890.1.5.8.45.27
.2.2
This trap is sent when all
device operating
parameters return to the
normal operating range.
