Chapter 41 Troubleshooting
MES-3728 User’s Guide
357
41.3 Switch Configuration
I lost my configuration settings after I restart the Switch.
Make sure you save your configuration into the
Switch’s nonvolatile memory each time you make
changes. Click Save at the top right corner of the
web configurator to save the configuration permanently. See also Section 33.3 on
page 298 for more information about how to save your configuration.
